SUN HYDRAULICS
CAVITY PLUG
XQOAXXN
$83.80
- SUN HYDRAULICS
- Material:XQOAXXN
- Model:XQOA-XXN
- Summary:Cartridge
Quantity in stock: 3
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics XQOAXXN (XQOAXXN) is a versatile cavity plug designed for use in both four-port and six-port cavities. When implemented in four-port cavities such as T21A, T22A, T23A, and T24A, it connects ports 1 and 2 while blocking ports 3 and 4. In six-port cavities like T61A, T62A, T63A, and T64A, it connects ports 1 through 4 and blocks ports 5 and 6. This plug is part of the Series 4 line and can withstand a maximum operating pressure of up to 5000 psi (350 bar). The valve has a hex size of 1-5/8 inches (41.3 mm) and requires an installation torque ranging from 350 to 375 lbf-ft (474 to 508 Nm). It utilizes a Viton seal kit for optimal performance. The XQOAXXN is built with corrosion resistance in mind, offering zinc-nickel plating for enhanced durability. Additionally, Sun Hydraulics provides resources such as QuickDesign with SmartConnect for schematic designs and Series 4 PLUS cartridges that offer higher flows with lower pressure losses. This product is ideal for applications requiring reliable sealing solutions in hydraulic systems while maintaining high-performance standards under demanding conditions.
The Sun Hydraulics XQOAXXN (XQOAXXN) is a versatile cavity plug designed for use in both four-port and six-port cavities. When implemented in four-port cavities such as T21A, T22A, T23A, and T24A, it connects ports 1 and 2 while blocking ports 3 and 4. In six-port cavities like T61A, T62A, T63A, and T64A, it connects ports 1 through 4 and blocks ports 5 and 6. This plug is part of the Series 4 line and can withstand a maximum operating pressure of up to 5000 psi (350 bar). The valve has a hex size of 1-5/8 inches (41.3 mm) and requires an installation torque ranging from 350 to 375 lbf-ft (474 to 508 Nm). It utilizes a Viton seal kit for optimal performance. The XQOAXXN is built with corrosion resistance in mind, offering zinc-nickel plating for enhanced durability. Additionally, Sun Hydraulics provides resources such as QuickDesign with SmartConnect for schematic designs and Series 4 PLUS cartridges that offer higher flows with lower pressure losses. This product is ideal for applications requiring reliable sealing solutions in hydraulic systems while maintaining high-performance standards under demanding conditions.
These cavity plugs can be used for both four-port and six-port cavities. When used in four-port cavities (T-21A, T-22A, T-23A and T-24A), ports 1 and 2 remain connected and ports 3 and 4 are blocked. When used in six-port cavities (T-61A, T-62A, T-63A and T-64A), ports 1, 2, 3 and 4 remain connected and ports 5 and 6 are blocked.
| Cavity | T-24A & T-64A |
| Series | 4 |
| Maximum Operating Pressure | 5000 psi350 bar |
| Valve Hex Size | 1 5/8 in.41,3 mm |
| Valve Installation Torque | 350 - 375 lbf ft474 - 508 Nm |
| Seal kit - Cartridge | Viton: 990-024-006 |
