UNI-GRIP™ SERIES AND DUALSPREAD™
Integrated Plow & Spreader Controls
The Uni-Grip Series provides effective plow controls via performance, power and precision. Available with fully proportional capabilities and multi-function control in three different configurations, the Uni-Grip™ series of single joysticks from Certified Power Solutions offer precision operations for superior winter maintenance. The Uni-Grip series utilizes our sophisticated Mako™ software, which allows operators to individually program the speed of each direction of motion without changing wiring or making hydraulic modifications. The Dual Spread™ control system provides simple, accurate open- or closed-loop controls for spreading applications including granular and pre-wet. The Dual Spread offers 6 programmable rates for augers, spinners and liquid applications.
REQUEST QUOTE
| DUALSPREAD PRODUCT APPLICATION |
| Granular and liquid spreading for snow and ice applications |
| DUALSPREAD 3 OPEN- OR CLOSED-LOOP SPREADING CHANNELS |
| Auger, spinner and pre-wet |
| DUALSPREAD COMPENSATION FOR CHANGES IN LANE WIDTH SETTINGS |
| Area spreading in lbs/gal per lane mile |
| Distance spreading in lbs/gal per mile |
| DUALSPREAD MATERIAL DESIGNATION |
| Up to 6 types of granular and 6 types of liquid with customized application rates for each |
| DUALSPREAD DATA LOGGING BY MATERIAL NAME |
| Select specific application rates, definitions and related data logging for specific purposes (i.e., state vs. county vs. city roads) |
| DUALSPREAD STORM AND SEASON TOTALS |
| System logs application amounts by rate definition for the storm and the season (storm total is operator resettable) |
| DUALSPREAD AVL READY |
| Compatible with many brands of radio and cell phone AVL systems |
| DUALSPREAD BLAST AND PASS (PAUSE) |
| Blast is programmable (on/off, timed, momentary) |
| Remote blast and pass accessible |
| DUALSPREAD OUTPUT SIGNAL |
| Multiple frequency settings for ease-of-valve compatibility |
| DUALSPREAD POWER SAFETY |
| Power Safe™ signals prevents random grounds powering any hydraulics system attached (auger, spinner, conveyor, etc.) |
| Channel Safe™ detects and protects against open or short circuits on hydraulic drive channels |
| DUALSPREAD DISPLAY TYPE |
| 4 lines x 20 characters on the white/blue graphic LCD |
| DUALSPREAD SYSTEM MOUNTING |
| Seat mounted or pedestal mounted |
| Standalone |
| DUALSPREAD WARNING INDICATORS |
| Integrated visible (LCD) and audible (buzzer) for spreading alarms |
| DUALSPREAD OPTIONAL EQUIPMENT |
| Data Shark™ with Drive by Download™ for data logging and wireless download |
| DUALSPREAD OPERATING TEMPERATURE RANGE |
| Minimum: –20 degrees Celsius; maximum: 70 degrees Celsius |
| DUALSPREAD POWER REQUIREMENTS |
| Minimum: 11 Volts DC |
| Maximum: 15 Volts DC |
| Maximum: 10 Amps |
| Fuses rated at 10 Amps |
| UNI-GRIP FEATURES |
| Uni-Grip 412, 620 and 820 models |
| Fully proportional single joystick |
| 2- or 3-axis options |
| Multi-function control |
| Standard safety grip trigger |
| Controls up to 7 hydraulic devices |
| Control up to 20 proportional channels on one stick |
| Configurable FOR patrol, garbage AND leaf collection vehicles |
| Easy capability upgrade options with Mako electronics platform |
| UNI-GRIP PRODUCT SUMMARY |
| Single joystick for proportional control of hydraulic devices (e.g., hoist, plow, wing, blade) |
| Utilizes Mako Trim™, a Windows® compatible program to set the speed of each direction of motion individually without wiring or hydraulic modifications |
| UNI-GRIP PRODUCT APPLICATION |
| Multiple vehicle types (patrol trucks for snow/ice, sanitation, leaf collection, etc.) |
| Control of each hydraulic function independently |
| UNI-GRIP DEVICE AND SIGNAL CAPACITY |
| UG 412 - up to 3 devices; 12 independent PWM channels |
| UG 620 - up to 5 devices; 20 independent PWM channels |
| UG 820 - up to 7 devices; 20 independent PWM channels |
| Frequency range from 40 – 450 Hz |
| UNI-GRIP JOYSTICK BUTTONS |
| UG 412 - 2 programmable buttons |
| UG 620 - 4 programmable buttons |
| UG 820 - 6 programmable buttons |
| UNI-GRIP AXIS AND RANGE OF JOYSTICK MOTION |
| UG 412 - 2 axes of joystick motion: X and Y |
| UG 620 - 3 axes of joystick motion: X, Y and Z |
| UG 820 - 3 axes of joystick motion: X, Y and Z |
| 27 degrees of motion available in each axis |
| UNI-GRIP JOYSTICK SIGNAL |
| True Hall effect (Magnetic) joystick with no mechanical contacts |
| UNI-GRIP JOYSTICK SELF TEST DIAGNOSTICS WITH CAN BUS |
| Mako uses CAN bus for a self test of the joystick during each power cycle |
| SafeStik™ automatically disables the axis if an axis fails during use |
| Joystick diagnostics visible on LED, LCD or at valve body |
| Channel Safe™ detects and protects against open or short circuits in hydraulic drive channels |
| UNI-GRIP COMBO UP (PANIC) FUNCTION |
| Momentary button trigger for parking of up to 6 devices |
| UNI-GRIP FLOAT FUNCTIONS |
| User settable float controls for plow, wing toe, wing heel and blade |
| UNI-GRIP PLOW CONTROL INTERLOCKED FEATURES |
| Hoist lock, hoist limit, plow, wing and blade lock (requires external sensor, key or switch) |
| UNI-GRIP ELECTRONIC BACKPACK |
| Mako multiplexed on CAN bus and Certified Power Solutions bus |
| UNI-GRIP SYSTEM CONTROLLER |
| Mako Trim works on any Windows® 2000 (or newer) computer |
| Field configurable buttons and function names |
| UNI-GRIP DISPLAY TYPE |
| UG 412 - LED indication mounted in joystick head |
| UG 620 - graphic LCD (white/blue) or optional color TFT |
| UG 820 - graphic LCD (white/blue) or optional color TFT |
| UNI-GRIP SYSTEM MOUNTING |
| Seat mounted or pedestal mounted |
| UNI-GRIP WARNING INDICATORS |
| Up to 8 labeled and colored indicators integrated into the joystick housing |
| UNI-GRIP OPTIONAL EQUIPMENT |
| Uni-Grip control of plow float and Moray™ system |
| UNI-GRIP OPERATING TEMPERATURE RANGE |
| Minimum: –20 degrees Celsius; maximum: 70 degrees Celsius |
| UNI-GRIP POWER REQUIREMENTS |
| Minimum: 11 Volts DC |
| Maximum: 15 Volts DC |
| Maximum: 10 Amps |
| Internal fuse rated at 10 Amps |
