POWERSMART™ — CENTRALIZED POWER SYSTEM
Electronic Controls & Accessories
PowerSmart™ is a 12-volt DC, solid state printed circuit assembly that improves the installation of snowplow truck equipment accessories by providing a central power and connection point for switches, sensors, relay controlled devices and Certified Power Solutions accessory products.
REQUEST QUOTE
| SUMMARY |
| Standardize truck body wiring across multiple end users and equipment sets |
| Faster troubleshooting with common wiring, labels and LED notifications on board |
| Extra relays on board allow installers to “plug and play” for specific functions |
| MAIN POWER CAPACITY |
| 12 volts DC, 120 Amps max when connected to vehicle battery with 4awg wire |
| On board clamp diode protects equipment from voltage spikes |
| “Ignition hot” wire turns system on and off with truck ignition |
| POWER CONTACTS |
| 12 volts, general purpose power points with individual fuses up to 30 Amps each |
| Power points for Certified Power Solutions modules, each 15 Amps, and 30 Amps for electric pre-wet driver |
| Each power point has a red LED to indicate power status |
| SENSOR INPUTS |
| Powered by individual 5-amp fuse with red LED for power status |
| Green LED indicates sensor state = true |
| SWITCH INTERFACES |
| 10-amp fuse for each switch, red LED indicates power |
| Normally open and normally closed contacts available for use — Normally open spades, yellow LED — Normally closed spades, blue LED |
| CONTROL RELAYS |
| 10-amp fuse for each relay, red LED indicates power with trigger spade (green LED) |
| Normally open and normally closed contacts available for each — Normally open spades, yellow LED — Normally closed spades, blue LED |
