SUN HYDRAULICS
RPGEQVV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RPGEQVV (RPGEQVV) is a fast-acting, pilot-operated, balanced piston relief cartridge designed to protect hydraulic components from pressure transients. This normally closed, pressure-limiting valve quickly opens and closes to manage pressure surges but may sacrifice some smoothness in operation. When the inlet port reaches the designated valve setting, the valve opens to the tank port, throttling flow to maintain pressure levels. It features a low-pressure rise versus flow and responds rapidly with a typical response time of 2 milliseconds. The valve is designed for interchangeability across all 2-port relief cartridges, sharing the same flow path and cavity for its frame size. This model can handle maximum pressures at port 2 and is suitable for cross-port relief circuits, though users should consider spool leakage in such applications. It includes a main stage orifice protected by a 150-micron stainless steel screen but is not recommended for load-holding applications due to potential spool leakage. Back pressure on the tank port directly influences valve settings at a 1:1 ratio. Configurations with EPDM seals are intended for systems using phosphate ester fluids; exposure to petroleum-based substances can damage these seals. The RPGEQVV incorporates Sun's floating style construction, which reduces risks of internal binding due to installation torque or machining variations. It supports capacities up to 50 gpm (200 L/min) and operates under maximum pressures of 5000 psi (350 bar). The cartridge features an adjustment range facilitated by five clockwise turns and has specific installation requirements including torque values for both the valve and locknut components.
