SUN HYDRAULICS
LINE MOUNT BODY
HCN
$124.50 USD
- SUN HYDRAULICS
- Material:HCN
- Summary:Manifold
Quantity in stock: 1
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics HCN (HCN) is a line mount manifold designed for versatile hydraulic applications. It features a ninety-degree body type with two mounting holes, each having a diameter of 0.42 inches (10.7 mm), and allows for through-hole depth mounting. The manifold is constructed with one open cavity, specifically the T-17A cavity, and is compatible with SAE 20 port sizes. Made from 6061-T651 aluminum, this manifold offers exceptional corrosion resistance without the need for anodizing, which can reduce fatigue life significantly by up to 50%. This material choice ensures durability and reliability in various environments while maintaining cost-effectiveness and availability in diverse shapes and sizes. Additionally, the manifold supports high flow valves, making it suitable for demanding hydraulic systems. It is important to note that the maximum system pressure should be carefully considered, as aluminum manifolds are not rated for pressures exceeding 3000 psi (210 bar). This product provides robust plumbing solutions without requiring additional wear surfaces or anodization processes due to its inherent material properties.
The Sun Hydraulics HCN (HCN) is a line mount manifold designed for versatile hydraulic applications. It features a ninety-degree body type with two mounting holes, each having a diameter of 0.42 inches (10.7 mm), and allows for through-hole depth mounting. The manifold is constructed with one open cavity, specifically the T-17A cavity, and is compatible with SAE 20 port sizes. Made from 6061-T651 aluminum, this manifold offers exceptional corrosion resistance without the need for anodizing, which can reduce fatigue life significantly by up to 50%. This material choice ensures durability and reliability in various environments while maintaining cost-effectiveness and availability in diverse shapes and sizes. Additionally, the manifold supports high flow valves, making it suitable for demanding hydraulic systems. It is important to note that the maximum system pressure should be carefully considered, as aluminum manifolds are not rated for pressures exceeding 3000 psi (210 bar). This product provides robust plumbing solutions without requiring additional wear surfaces or anodization processes due to its inherent material properties.
Body Type | Line mountLine mount |
Interface | NoneNone |
Body Features | Ninety degreeNinety degree |
Mounting Hole Diameter | .42 in.10,7 mm |
Mounting Hole Depth | ThroughThrough |
Mounting Hole Quantity | 22 |
Open Cavities | 11 |
Cavity | T-17A |
Port Size | SAE 20SAE 20 |
Show FAQ
Additional Resources
- QuickDesign with SmartConnect Offers Drag-and-Drop Schematic Tool
- Standard Line Mount Manifolds for High Flow Valves
- Manufacturing Sun Cartridge Cavities
- Manifolds: Materials of Construction
- Sun's Floating Style Screw-In Cartridge
- Sun Model Code Explanation; 999-901-334
- Custom Integrated Packages from Sun
- Fluid and Temperature Recommendations
- QuickDesign & SunDesign: Sun's 3- & 5-Axis Solutions
Notes:
- Important: Carefully consider the maximum system pressure. The pressure rating of the manifold is dependent on the manifold material, with the port type/size a secondary consideration. Manifolds constructed of aluminum are not rated for pressures higher than 3000 psi (210 bar), regardless of the port type/size specified.
