SUN HYDRAULICS
PLUG
XNOAXXN
$35.10 USD
- SUN HYDRAULICS
- Material:XNOAXXN
- Model:XNOA-XXN
- Summary:Cartridge
Quantity in stock: 1
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics XNOAXXN (XNOAXXN) is a versatile cavity plug designed for use in both four-port and six-port cavities. In four-port configurations such as T21A, T22A, T23A, and T24A, it connects ports 1 and 2 while blocking ports 3 and 4. In six-port configurations like T61A, T62A, T63A, and T64A, it maintains connections between ports 1 through 4 while blocking ports 5 and 6. This product is suitable for applications requiring reliable sealing under high pressure conditions, with a maximum operating pressure of up to 5000 psi (350 bar). The valve hex size is precisely measured at 1-1/8 inches (28.6 mm), ensuring a secure fit during installation. Installation torque specifications range from 45 to 50 lbf-ft (61 to 68 Nm), providing a robust seal under operational stress. The cavity plug comes with a Viton seal kit cartridge (part number: 990022006), offering excellent resistance to hydraulic fluids and high temperatures. With its advanced design features, the Sun Hydraulics XNOAXXN cavity plug enhances system reliability by preventing unwanted fluid flow in unused ports, thus optimizing performance in hydraulic systems.
The Sun Hydraulics XNOAXXN (XNOAXXN) is a versatile cavity plug designed for use in both four-port and six-port cavities. In four-port configurations such as T21A, T22A, T23A, and T24A, it connects ports 1 and 2 while blocking ports 3 and 4. In six-port configurations like T61A, T62A, T63A, and T64A, it maintains connections between ports 1 through 4 while blocking ports 5 and 6. This product is suitable for applications requiring reliable sealing under high pressure conditions, with a maximum operating pressure of up to 5000 psi (350 bar). The valve hex size is precisely measured at 1-1/8 inches (28.6 mm), ensuring a secure fit during installation. Installation torque specifications range from 45 to 50 lbf-ft (61 to 68 Nm), providing a robust seal under operational stress. The cavity plug comes with a Viton seal kit cartridge (part number: 990022006), offering excellent resistance to hydraulic fluids and high temperatures. With its advanced design features, the Sun Hydraulics XNOAXXN cavity plug enhances system reliability by preventing unwanted fluid flow in unused ports, thus optimizing performance in hydraulic systems.
These cavity plugs can be used for both four-port and six-port cavities. When used in four-port cavities (T-21A, T-22A, T-23A and T-24A), ports 1 and 2 remain connected and ports 3 and 4 are blocked. When used in six-port cavities (T-61A, T-62A, T-63A and T-64A), ports 1, 2, 3 and 4 remain connected and ports 5 and 6 are blocked.
| Cavity | T-22A & T-62A |
| Series | 2 |
| Maximum Operating Pressure | 5000 psi350 bar |
| Valve Hex Size | 1 1/8 in.28,6 mm |
| Valve Installation Torque | 45 - 50 lbf ft61 - 68 Nm |
| Seal kit - Cartridge | Viton: 990-022-006 |
