SUN HYDRAULICS
WJY/V

$225.70 USD

SUN HYDRAULICS
Material:WJY/V
Summary:Manifold

Quantity in stock: 0

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics WJY/V (Material Number: WJY/V) is a specialized hydraulic subplate designed for use with ISO 05 interface systems. This product features a body type that incorporates a P to T channel with a check valve on the P port, ensuring efficient flow control and pressure management. The subplate is constructed with bottom ports and includes an open cavity labeled as 11CavityT10A, which allows for versatile hydraulic configurations. It is crafted from 6061T651 aluminum, known for its excellent corrosion resistance and durability, making it suitable for various hydraulic applications where reliability and longevity are crucial. This material choice ensures the subplate can withstand pressures up to 3000 psi (210 bar), although users should carefully consider system pressure limitations based on the manifold's material. The design of this subplate does not include anodizing, as Sun Hydraulics opts to maintain the natural properties of the aluminum, which are sufficient for most applications without additional surface treatments. This decision also helps avoid issues related to increased breakaway torque and potential fatigue life reduction associated with anodized surfaces. Overall, the Sun Hydraulics WJY/V subplate offers robust performance in hydraulic systems requiring efficient flow control and reliable operation within specified pressure limits.

Description

Body Type	SubplateSubplate
Interface	ISO 05ISO 05
Body Features	P to T, check on P, bottom portsP to T, check on P, bottom ports
Open Cavities	11
Cavity	T-10A

Show FAQ

Why doesn't Sun anodize their aluminum bodies?	Reasons to anodize: To increase corrosion resistance. Sun uses 6061-T651 aluminum. It is one of the most corrosion resistant aluminum alloys there is. Whether or not anodizing improves the corrosion resistance of 6061 aluminum is debatable. We have yet to have a manifold returned because of corrosion. Appearance (color). The 2 colors that would appeal to Sun would be blue or black. Unfortunately these are the colors that are hardest to do consistently. To provide a hard wear surface. Sun does not make parts-in-body valves. The manifold is just plumbing. We don't need a wear surface. Because everyone else does it. Bad reason. Reasons to not anodize: Cost. It's another process. Logistics. When you make tens of thousands of manifolds a month and you anodize hundreds, it's a problem. Consistency. See above. Stamping. After a body is anodized you cannot do any more stamping without making a mess.Inspection. Have you ever tried to look for burrs in a black anodized body? It's the old blackboard factory at night scenario. Torque. You will experience an increase in breakaway torque when removing items from an anodized manifold. Fatigue life. This is the best reason to not anodize. Fatigue failure is a very complex phenomenon. What it takes to initiate a crack is difficult to predict. What it takes to propagate a crack is readily defined. Anodizing produces a very thin, very hard, and very brittle surface on aluminum. The first time you pressurize an anodized aluminum manifold you have initiated fatigue cracks. Whether or not the stress is enough to propagate the cracks is a matter of pressure and manifold geometry. Anodizing an aluminum manifold grossly reduces the fatigue life by anywhere from 20% to 50%.
How big is a drop of hydraulic oil?	There are exactly 250 Sun drops in a cubic inch or 15 in a cc.
Why does Sun use 6061 aluminum?	6061-T651 is relatively strong, relatively inexpensive, difficult to machine, readily available in all shapes and sizes and very corrosion resistant. 2024 is stronger and machines beautifully, but is expensive and falls to pieces in a corrosive environment.

Additional Resources

Notes:

Important: Carefully consider the maximum system pressure. The pressure rating of the manifold is dependent on the manifold material, with the port type/size a secondary consideration. Manifolds constructed of aluminum are not rated for pressures higher than 3000 psi (210 bar), regardless of the port type/size specified.
