SUN HYDRAULICS
U8X

$89.40 USD

SUN HYDRAULICS
Material:U8X
Summary:Manifold

Quantity in stock: 0

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics U8X (Material Number: U8X) is a line mount hydraulic manifold designed for versatile applications in fluid control systems. This component features a body type specifically tailored for line mounting and includes common port 1 with coil clearance, making it suitable for various hydraulic setups. The open cavities are designated as 22Cavity T13A, and the port size is SAE 8, ensuring compatibility with standardized hydraulic connections. Constructed from 6061T651 aluminum, the manifold offers a balance of strength, cost-effectiveness, and corrosion resistance without the need for anodizing. The material choice ensures durability while maintaining the integrity of the component in corrosive environments. It is important to note that this manifold is not rated for pressures exceeding 3000 psi (210 bar), regardless of the port type or size specified. This makes it essential to carefully consider maximum system pressure during application to avoid exceeding these limits. The U8X model provides reliable performance in managing fluid dynamics within hydraulic systems and can be integrated into existing setups that meet its specifications.

Description

Body Type	Line mountLine mount
Body Features	Common port 1 with coil clearanceCommon port 1 with coil clearance
Open Cavities	22
Cavity	T-13A
Port Size	SAE 8SAE 8

Show FAQ

Why does Sun use 6061 aluminum?	6061-T651 is relatively strong, relatively inexpensive, difficult to machine, readily available in all shapes and sizes and very corrosion resistant. 2024 is stronger and machines beautifully, but is expensive and falls to pieces in a corrosive environment.
Why doesn't Sun anodize their aluminum bodies?	Reasons to anodize: To increase corrosion resistance. Sun uses 6061-T651 aluminum. It is one of the most corrosion resistant aluminum alloys there is. Whether or not anodizing improves the corrosion resistance of 6061 aluminum is debatable. We have yet to have a manifold returned because of corrosion. Appearance (color). The 2 colors that would appeal to Sun would be blue or black. Unfortunately these are the colors that are hardest to do consistently. To provide a hard wear surface. Sun does not make parts-in-body valves. The manifold is just plumbing. We don't need a wear surface. Because everyone else does it. Bad reason. Reasons to not anodize: Cost. It's another process. Logistics. When you make tens of thousands of manifolds a month and you anodize hundreds, it's a problem. Consistency. See above. Stamping. After a body is anodized you cannot do any more stamping without making a mess.Inspection. Have you ever tried to look for burrs in a black anodized body? It's the old blackboard factory at night scenario. Torque. You will experience an increase in breakaway torque when removing items from an anodized manifold. Fatigue life. This is the best reason to not anodize. Fatigue failure is a very complex phenomenon. What it takes to initiate a crack is difficult to predict. What it takes to propagate a crack is readily defined. Anodizing produces a very thin, very hard, and very brittle surface on aluminum. The first time you pressurize an anodized aluminum manifold you have initiated fatigue cracks. Whether or not the stress is enough to propagate the cracks is a matter of pressure and manifold geometry. Anodizing an aluminum manifold grossly reduces the fatigue life by anywhere from 20% to 50%.
How big is a drop of hydraulic oil?	There are exactly 250 Sun drops in a cubic inch or 15 in a cc.

Additional Resources

Notes:

Important: Carefully consider the maximum system pressure. The pressure rating of the manifold is dependent on the manifold material, with the port type/size a secondary consideration. Manifolds constructed of aluminum are not rated for pressures higher than 3000 psi (210 bar), regardless of the port type/size specified.
