HYDRAFORCE
5503607

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5503607 (5503607) is a high-performance hydraulic solenoid valve characterized by its robust design and versatile functionality. This model, known as the HSP1047DX, is a proportional, 4-port, 3-position spool type motor spool valve. It operates as a screw-in, cartridge-style unit, making it suitable for compact system integration. The valve features multiple flow paths depending on its energization state: when de-energized, it blocks the inlet port while allowing flow from ports 2 and 4 to port 1; energizing s1 coil permits flow from port 3 to 4 and from port 2 to 1; and activating s2 coil enables flow from port 3 to port 2 and from port 4 to port 1. Designed for high-pressure applications, the HSP1047DX ensures efficient control with its continuous-duty rated coils and efficient wet-armature construction. The manual override operation includes a detailed mechanism for shifting the valve manually in emergency scenarios without relying on continuous operation. This feature enhances the operational safety and flexibility of the device. Moreover, this model boasts industry-standard cavity compatibility which simplifies installation processes across various applications. Durability is a key aspect of this valve's design; it includes waterproof E-Coils rated up to IP69K for superior environmental resistance and patented high-strength solenoid tubes that are salt-spray tested for up to 960 hours ensuring long-term reliability even in harsh conditions. All performance metrics are rigorously tested according to NFPA specification T2.6.1., with a verification level of 90% and an assurance level of 99%, highlighting its reliability in critical applications.
