HYDRAFORCE
5470113

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce HP10-20D-6T-N (5470113) is a robust and versatile hand pump designed for hydraulic applications, specifically tailored for emergency operations such as braking or brake release in battery-powered vehicles, as well as acting as a lube pump. This model is a push and release type with a return spring, featuring two built-in checks. It operates efficiently with general purpose hydraulic oils and integrates seamlessly into systems due to its screw-in cartridge design. The HP10-20D-6T-N can withstand a pressure rating of up to 207 bar (3000 psi) at Port 1 and 69 bar (1000 psi) at Port 2, with a maximum attainable pressure of 17 bar (250 psi) when exerting a push force of 133 N (30 lbf). This hand pump has a displacement of 1.36 ml per stroke, ensuring precise fluid control. Its operational fluid temperature ranges from -40 to +120 degrees Celsius (-40 to +248 degrees Fahrenheit), making it suitable for various environmental conditions. Additionally, the HP10-20D-6T-N features minimal internal leakage of only 0.15 ml/min (equivalent to about 3 drops/min) from port 1 to port 2 at its maximum pressure, showcasing its reliability and efficiency in maintaining system integrity. For installation, it utilizes standard size “10-size-2-way” cavities which simplifies integration into existing hydraulic systems. The hand pump also comes with optional accessories like seal kits which include installation instructions and is compatible with '102w valve bodies' housings, enhancing its adaptability for different setups.
