HYDRAFORCE
5436966
$126.50 USD
- HYDRAFORCE
- Material:5436966
- Model:FD50-45-8D-N-66 FLOW DIVIDER
- Summary:FLOW DIVIDER/COMBINER VALVE
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce FD50-45-8D-N-66 (5436966) is a screw-in cartridge, spool-type flow divider/combiner valve engineered to provide pressure-compensated proportional division of inlet flow or the combining of two return flows, independent of system operating pressure conditions. This product ensures synchronized flow in both dividing and combining modes, making it highly effective for applications requiring precise flow management. The valve is designed for use with mineral-based or synthetic hydraulic fluids that have lubricating properties. Key features include hardened parts that ensure longevity and durability under demanding conditions. Its quiet, modulated response prevents system shocks and vibrations, contributing to the stability and efficiency of the hydraulic system. The FD50-45-8D-N-66 operates within a wide flow range, from 19 to 57 liters per minute (5.0 to 15.0 gallons per minute), with a pressure rating up to 345 bar (5000 psi) and a maximum pressure drop of 20.5 bar (300 psi). Flow accuracy stands at ±15% of maximum inlet flow, ensuring reliable performance. Additional technical specifications include a floating cage for high installation torque tolerance and an industry-common cavity VC104, compatible with standard installations. The unit weighs approximately 0.49 kg (1.07 lb) and offers options for customization through accessories like seal kits (SK104NMMM) and housings for specific installation requirements. This valve is particularly suited for systems where precise synchronization of flow is critical, such as in advanced hydraulic circuits used in various industrial applications. Its robust design also makes it suitable for environments where reliability and noise reduction are prioritized.
The Hydraforce FD50-45-8D-N-66 (5436966) is a screw-in cartridge, spool-type flow divider/combiner valve engineered to provide pressure-compensated proportional division of inlet flow or the combining of two return flows, independent of system operating pressure conditions. This product ensures synchronized flow in both dividing and combining modes, making it highly effective for applications requiring precise flow management. The valve is designed for use with mineral-based or synthetic hydraulic fluids that have lubricating properties. Key features include hardened parts that ensure longevity and durability under demanding conditions. Its quiet, modulated response prevents system shocks and vibrations, contributing to the stability and efficiency of the hydraulic system. The FD50-45-8D-N-66 operates within a wide flow range, from 19 to 57 liters per minute (5.0 to 15.0 gallons per minute), with a pressure rating up to 345 bar (5000 psi) and a maximum pressure drop of 20.5 bar (300 psi). Flow accuracy stands at ±15% of maximum inlet flow, ensuring reliable performance. Additional technical specifications include a floating cage for high installation torque tolerance and an industry-common cavity VC104, compatible with standard installations. The unit weighs approximately 0.49 kg (1.07 lb) and offers options for customization through accessories like seal kits (SK104NMMM) and housings for specific installation requirements. This valve is particularly suited for systems where precise synchronization of flow is critical, such as in advanced hydraulic circuits used in various industrial applications. Its robust design also makes it suitable for environments where reliability and noise reduction are prioritized.
Unit weight:
0.49 kg (1.07 lb)
| Ratings | Pressure Ratings Pressure rating: 345 bar (5000 psi) Pressure drop: 20.5 bar (300 psi) At maximum inlet flow Flow Ratings Inlet flow rating: 19 to 57 lpm (5.0 to 15.0 gpm) Synchronizing flow: Approximately 10% of maximum inlet flow Flow accuracy: 15 % Of inlet flow (maximum) |
| Performance |  |
| Installation Specifications | Cavity:
VC10-4 10-size-4-way Cavities |
| Order Code | POSITION CODE DESCRIPTION FD50-45-H-J-N H Line Body H 0 No Body H 6T Aluminum SAE 6 H 6TD Ductile Iron SAE 6 J Seal J N Buna-N J V Fluorocarbon J P Polyurethane N Flow Dividing/Combining N 22 50/50 Rated at 4.0-19.0 lpm (1.0-5.0 gpm) N 33 50/50 Rated at 5.5-26.5 lpm (1.5-7.0 gpm) N 44 50/50 Rated at 9.5-38.0 lpm (2.5-10.0 gpm) N 55 50/50 Rated at 11.5-41.5 lpm (3.0-11.0 gpm) N 66 50/50 Rated at 15.0-45.0 lpm (4.0-12.0 gpm) N 88 50/50 Rated at 19.0-57.0 lpm (5.0-15.0 gpm) |
Seal kit:
SK10-4N-MMM
Seal kit installation instructions
Housings:
Available
10-4w valve bodies
