HYDRAFORCE
5436366
$64.25 USD
- HYDRAFORCE
- Material:5436366
- Model:FD50-45-0-N-66 FLOW DIVIDER
- Summary:FLOW DIVIDER/COMBINER VALVE
Due to extremely high demand, please call 888-905-7411 for availability
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce FD50-45-0-N-66 (5436366) is a state-of-the-art screw-in cartridge, spool type flow divider/combiner valve designed for advanced fluid management in hydraulic systems. This valve excels in pressure compensated proportional division of inlet flow or combining of two return flows irrespective of the variations in system operating pressure conditions. It ensures accurate synchronization of flow whether in dividing or combining mode, making it a versatile component suitable for a broad range of applications. The FD50-45-0-N-66 is engineered to work efficiently with mineral-based or synthetic hydraulic fluids that possess lubricating properties. Its design includes hardened parts which ensure longevity and durability even under rigorous use. The valve operates quietly with a modulated response and supports a wide operating flow range from 19 to 57 liters per minute (5.0 to 15.0 gallons per minute). The precision in flow division or combination is maintained within ±15% of the maximum inlet flow, ensuring operational reliability and efficiency. Additionally, the unit features a floating cage that allows high installation torque and utilizes an industry-common cavity (VC104), facilitating ease of installation and compatibility with existing systems. The robust construction coupled with high-pressure ratings up to 345 bar (5000 psi) and a maximum inlet flow pressure drop of 20.5 bar (300 psi) underscores its capability to handle demanding applications seamlessly. This model also comes with optional accessories such as seal kits (SK104NMMM) and housings for specific configurations, enhancing its adaptability across different setups. Weighing approximately 0.49 kg (1.07 lb), the FD50-45-0-N-66 combines compact design with powerful performance, making it an essential component for efficient hydraulic operations.
The Hydraforce FD50-45-0-N-66 (5436366) is a state-of-the-art screw-in cartridge, spool type flow divider/combiner valve designed for advanced fluid management in hydraulic systems. This valve excels in pressure compensated proportional division of inlet flow or combining of two return flows irrespective of the variations in system operating pressure conditions. It ensures accurate synchronization of flow whether in dividing or combining mode, making it a versatile component suitable for a broad range of applications. The FD50-45-0-N-66 is engineered to work efficiently with mineral-based or synthetic hydraulic fluids that possess lubricating properties. Its design includes hardened parts which ensure longevity and durability even under rigorous use. The valve operates quietly with a modulated response and supports a wide operating flow range from 19 to 57 liters per minute (5.0 to 15.0 gallons per minute). The precision in flow division or combination is maintained within ±15% of the maximum inlet flow, ensuring operational reliability and efficiency. Additionally, the unit features a floating cage that allows high installation torque and utilizes an industry-common cavity (VC104), facilitating ease of installation and compatibility with existing systems. The robust construction coupled with high-pressure ratings up to 345 bar (5000 psi) and a maximum inlet flow pressure drop of 20.5 bar (300 psi) underscores its capability to handle demanding applications seamlessly. This model also comes with optional accessories such as seal kits (SK104NMMM) and housings for specific configurations, enhancing its adaptability across different setups. Weighing approximately 0.49 kg (1.07 lb), the FD50-45-0-N-66 combines compact design with powerful performance, making it an essential component for efficient hydraulic operations.
Unit weight:
0.49 kg (1.07 lb)
| Ratings | Pressure Ratings Pressure rating: 345 bar (5000 psi) Pressure drop: 20.5 bar (300 psi) At maximum inlet flow Flow Ratings Inlet flow rating: 19 to 57 lpm (5.0 to 15.0 gpm) Synchronizing flow: Approximately 10% of maximum inlet flow Flow accuracy: 15 % Of inlet flow (maximum) |
| Performance |  |
| Installation Specifications | Cavity:
VC10-4 10-size-4-way Cavities |
| Order Code | POSITION CODE DESCRIPTION FD50-45-H-J-N H Line Body H 0 No Body H 6T Aluminum SAE 6 H 6TD Ductile Iron SAE 6 J Seal J N Buna-N J V Fluorocarbon J P Polyurethane N Flow Dividing/Combining N 22 50/50 Rated at 4.0-19.0 lpm (1.0-5.0 gpm) N 33 50/50 Rated at 5.5-26.5 lpm (1.5-7.0 gpm) N 44 50/50 Rated at 9.5-38.0 lpm (2.5-10.0 gpm) N 55 50/50 Rated at 11.5-41.5 lpm (3.0-11.0 gpm) N 66 50/50 Rated at 15.0-45.0 lpm (4.0-12.0 gpm) N 88 50/50 Rated at 19.0-57.0 lpm (5.0-15.0 gpm) |
Seal kit:
SK10-4N-MMM
Seal kit installation instructions
Housings:
Available
10-4w valve bodies
