HYDRAFORCE
5410001

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce FC10-21A-0-N-05 (5410001) is a high-performance, screw-in, cartridge-style flow control valve designed for precise hydraulic flow management with a reverse flow check feature. This variable orifice valve offers robust control over hydraulic systems by adjusting from fully closed to fully open through a clockwise rotation. Engineered for durability and reliability, the FC10-21A-0-N-05 includes features that prevent adjustments from being backed out unintentionally, allowing settings to be securely locked down once desired parameters are achieved. The valve is crafted with hardened parts to enhance its lifespan and includes an optional aluminum knob for ease of adjustment. It is designed to provide positive shutoff with a linear adjustment mechanism, ensuring smooth operation within an industry-standard cavity (VC102A). The FC10-21A-0-N-05 supports a maximum flow rate of 57 liters per minute at full openness and withstands operating pressures up to 241 bar (3500 psi), with proof and burst pressures reaching up to 345 bar (5000 psi) and 896 bar (13000 psi) respectively. Temperature adaptability ranges from -40°C to +100°C with standard Buna N seals, extending up to +204°C with fluorocarbon seals. The valve operates effectively across a broad viscosity range of hydraulic fluids from 7.4 to 420 cSt and maintains performance within maximum operating contamination levels as specified by ISO 4406 standards. Weighing approximately 0.16 kg, the FC10-21A-0-N-05 is compact yet robust enough for demanding applications requiring precise fluid control without orientation restrictions during installation.
