HYDRAFORCE
5401500
$29.25 USD
- HYDRAFORCE
- Material:5401500
- Model:NV08-21T-0-N NEEDLE VALVE
- Summary:NEEDLE VALVE FINE METERING ADJUSTMENT
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5401500 (5401500) is a screw-in, cartridge-style, variable orifice hydraulic flow metering valve designed for precise fluid control in hydraulic systems. This model boasts a unique construction that prevents adjustments from being backed out of the valve, ensuring stable and consistent performance. The hardened parts within the valve contribute to its durability and extended lifespan, making it suitable for rigorous industrial use. Its fine, low-effort adjustment capability allows for meticulous control over multiple turns, facilitating precise metering and regulation of fluid flow. Moreover, the positive shutoff feature of the 5401500 enhances safety by completely stopping fluid flow when needed. Its compact design is compatible with industry-common cavities, ensuring easy integration into various hydraulic circuits without requiring extensive modifications.
The Hydraforce 5401500 (5401500) is a screw-in, cartridge-style, variable orifice hydraulic flow metering valve designed for precise fluid control in hydraulic systems. This model boasts a unique construction that prevents adjustments from being backed out of the valve, ensuring stable and consistent performance. The hardened parts within the valve contribute to its durability and extended lifespan, making it suitable for rigorous industrial use. Its fine, low-effort adjustment capability allows for meticulous control over multiple turns, facilitating precise metering and regulation of fluid flow. Moreover, the positive shutoff feature of the 5401500 enhances safety by completely stopping fluid flow when needed. Its compact design is compatible with industry-common cavities, ensuring easy integration into various hydraulic circuits without requiring extensive modifications.
Description A screw in, cartridge style, variable orifice, hydraulic flow metering valve. Operation It is intended for applications requiring fine adjustment over multiple turns. Features Adjustments cannot be backed out of the valve. Hardened parts for long life. Fine/Low-effort adjustment. Positive shut-off. Compact, industry-common cavity.
Operating torque required:
4 in-lb
At 3500 psi
| Ratings | Flow Ratings Flow rating: 15 gpm At 250 psid at full open (5.5 turns) 250 psid Maximum internal leakage: 3 drops/min Max. At shut off Pressure Ratings Pressure rating: 3500 psi Temperature Ratings Operating fluid temperature: -40 to 120 °C (-40 to 248 °F) |
| Performance |  |
| Installation Specifications | Cavity: 08-size-2-way Cavities |
| Order Code | POSITION CODE DESCRIPTION NV08-21F-H-J F Adjustment Option F E Plastic Knob F T Extended Shaft Only H Line Body H 0 No Body H 4T Aluminum SAE 4 H 6T Aluminum SAE 6 H 8T Aluminum SAE 8 H 6TD Ductile Iron SAE 6 H 8TD Ductile Iron SAE 8 H 2B Aluminum BSPP 1/4" (2) H 3B Aluminum BSPP 3/8" (3) H 3BD Ductile Iron BSPP 3/8" (3) J Seal J N Buna-N J V Fluorocarbon J P Polyurethane J U PPDI Urethane |
Seals:
Seal kit:
Seal kit installation instructions
Housings:
Available
08-2w valve bodies
