HYDRAFORCE
5314C01

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5314C01 (5314C01) is a high-performance, direct acting manual rotary spool valve designed for precise control in hydraulic systems. This model is a screw-in cartridge type valve, ideal for use with general purpose hydraulic fluids. It features a 3-position, 4-way directional control setup which enhances its adaptability to various hydraulic applications. The operational modes of the Hydraforce 5314C01 include three distinct positions: centered, 45 degrees counterclockwise, and 45 degrees clockwise. In its centered position, all ports of the valve are closed which helps in preventing any fluid flow through the system. When adjusted to 45 degrees counterclockwise from center, the valve allows fluid connectivity between ports 1 and 4 while also connecting ports 2 and 3. Conversely, adjusting the valve to 45 degrees clockwise from center opens up ports 1 and 2 while linking ports 3 and 4. This versatile configuration ensures that all ports are closed during transition between positions, thereby securing the hydraulic system from any potential leakage or pressure loss during operation adjustments. The adaptability of this model extends to its compatibility with various adjustment operators that can be ordered separately, allowing customization according to specific application requirements. The robust design of the Hydraforce 5314C01 makes it suitable for a wide range of applications requiring reliable directional control in their hydraulic circuits.
