HYDRAFORCE
5281153P

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5281153P (5281153P) is a high-performance hydraulic component designed for fluid power applications requiring consistent flow control. The EPFR16S35 model is a screw-in, cartridge-style, bypass type pressure compensating element that functions optimally with a remote fixed or variable orifice to maintain steady flow irrespective of load pressure variations. This valve features a spring-biased spool type design with an internal orifice between ports 2 and 3, which allows the valve to bypass all flow to the tank when reaching the bias spring pressure value plus any pressure rise during no load flow demand. The internal orifice of the 5281153P is uniquely engineered to be pressure compensated, which helps minimize flow loss through it when there is demand for load flow. This feature ensures high system efficiency and operational reliability in various hydraulic systems. The product offers multiple functions within a single cavity design, which simplifies installation and maintenance while reducing potential leak points. Additionally, the Hydraforce 5281153P provides low bleed flow across its operating pressure range, enhancing performance stability. It also comes with a range of bias spring options to accommodate different system pressures; however, it should be noted that taller adaptors are necessary for using higher pressures, specifically an extra tall adaptor for the 240 psi bias spring option. This versatility makes the Hydraforce 5281153P an ideal choice for those seeking a robust solution in hydraulic systems where space and efficiency are critical.
