HYDRAFORCE
5270304

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce MP08-30L-0-N (5270304) is a manually operated, 3-way directional hydraulic cartridge valve designed for robust performance in various hydraulic systems. This valve features a manual pull-to-shift mechanism with a spring return that simplifies operation and ensures reliable return to the neutral position. In its default state, the valve allows flow from port 2 to port 1 while blocking port 3. When actuated by pulling, it redirects the flow from port 3 to port 2 and blocks port 1. A unique optional feature of this model is its pull and rotate lock mechanism which requires a 90-degree rotation to maintain the valve in an actuated position, enhancing operational security and stability. Constructed with a hardened spool and cage, the MP08-30L-0-N ensures durability and a long service life even under challenging conditions. It supports up to 14 bar (200 psi) pressure at port 1, which is designated as a tank port only due to its pressure rating limitations. The valve's compact design adheres to industry-common cavity specifications, making it versatile for integration into various setups without requiring extensive modifications. The MP08-30L-0-N operates efficiently within a broad range of temperatures and is compatible with different seal materials—Buna N for standard temperature applications, fluorocarbon for higher temperatures, and urethane for specific operational needs—each providing optimal performance across varying environmental conditions. Additionally, this model facilitates easy maintenance with available seal kits specific to each seal type used in its construction. This manual cartridge valve is particularly suited for applications requiring reliable directional control of fluid flow in hydraulic circuits where manual operation is feasible or preferred.
