HYDRAFORCE
5261108

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce PD10-41-0-NS-110 (5261108) is a pilot-operated, spool-type hydraulic directional valve designed for robust performance in various applications. This cartridge-style valve operates by allowing flow from port 3 to 4 in its neutral position while blocking flow from port 2. A remote pilot signal at port 1 shifts the valve to enable flow from 3 to 2, concurrently blocking flow to port 4. This configuration is particularly notable as the pressure on port 4 affects the pilot pressure required due to its direct association with the spring chamber. The valve is engineered for durability, featuring a hardened spool and cage which ensure an extended operational life. The PD10-41-0-NS-110 is capable of handling pressures up to 241 bar (3500 psi) and can manage a maximum internal leakage of 82 ml/min at a pressure of 207 bar (3000 psi). It supports a wide range of operating fluid temperatures from -40°C to +100°C with Buna N seals, and even broader ranges with other seal types such as fluorocarbon and polyurethane. This makes it versatile for use with different fluids including mineral-based or synthetic hydraulic fluids that possess lubricating properties. Additionally, the valve fits into industry-standard VC104 cavities and does not require specific orientation upon installation, simplifying integration into various systems. The unit’s weight varies slightly depending on the model, ranging from approximately 0.19 kg to 0.27 kg. For maintenance or repair scenarios, seal kits like SK104XMMM are available along with installation instructions to ensure proper upkeep and functionality over time.
