HYDRAFORCE
5242002V

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce LS10-41-0-V (5242002V) is a high-performance shuttle valve designed for hydraulic applications requiring reliable fluid control. This screw-in, cartridge-style valve is spring-centered and features an inverted shuttle mechanism tailored for use with general-purpose hydraulic oils. It is engineered to operate efficiently with a blocked Port 1, making it versatile for integration into various hydraulic systems, including steering and brake circuits where it can charge two accumulators or control two brakes. Capable of handling pressures up to 3500 psi (241 bar) and operating within a temperature range of -40 to +212°F (-40 to +100°C) with standard Buna N seals, the LS10-41-0-V ensures robust performance in diverse environments. Alternative seal options like Viton and polyurethane extend the operational temperature capabilities further, up to 400°F (204°C) and down to 15°F (-26°C), respectively. The valve's maximum internal leakage is meticulously controlled, not exceeding 0.15 ml/min at 3000 psi (207 bar), highlighting its precision in fluid handling. This model's compatibility with both mineral-based and synthetic hydraulic fluids adds to its adaptability across different system requirements. The LS10-41-0-V also supports a wide fluid viscosity range from 7.4 to 420 cSt, ensuring effective operation even with varying fluid properties. Its internal wetted surface area measures around 18.7 inches (121 cm²), optimized for efficient fluid dynamics within the system. For installation, the LS10-41-0-V fits into a VC104 cavity and requires a torque between 24 to 26 ft-lb (32.6 to 35.4 Nm), allowing for secure and straightforward mounting without orientation restrictions. Optional accessories include various seal kits tailored for different environmental conditions, enhancing the valve’s utility and maintenance ease across numerous applications.
