HYDRAFORCE
5242002

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce LS10-41-0-N (5242002) is a versatile and robust shuttle valve designed for hydraulic applications requiring reliable directional control and fluid handling. This screw-in, cartridge-style valve features a spring-centered, inverted shuttle mechanism specifically tailored for use with general-purpose hydraulic oils. The LS10-41-0-N is engineered to facilitate operations such as charging dual accumulators or brakes in steering-brake circuits, showcasing its utility in various hydraulic systems. Constructed with hardened work surfaces and an industry-common cavity, the LS10-41-0-N ensures durability and compatibility across different installation setups. It offers significant operational flexibility with a pressure rating up to 241 bar (3500 psi) and accommodates a wide range of fluid viscosities from 7.4 to 420 cSt. The valve's maximum internal leakage is meticulously controlled, not exceeding 0.15 ml/min at 207 bar (3000 psi), which underscores its efficiency in maintaining system integrity. Temperature tolerance is another critical aspect of the LS10-41-0-N, supporting operating fluid temperatures from -40°C to +100°C with Buna N seals, -26°C to +204°C with Viton seals, and -54°C to +107°C with polyurethane seals. These specifications ensure that the valve performs reliably under varying environmental conditions without compromise. Additionally, the valve's compact design weighs only 0.13 kg (0.23 lb) and integrates seamlessly into systems via a VC104 cavity without orientation restrictions during installation. Optional accessories include seal kits available in Buna N, Viton, or polyurethane materials along with corresponding installation instructions, providing further customization and maintenance support tailored to specific system requirements.
