HYDRAFORCE
5241000

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce LS10-30-0-N (5241000) is a load shuttle, screw-in, cartridge-style hydraulic check valve designed for use in blocking circuits where priority of flow direction is given to a higher pressure circuit over a lower one. This model operates by allowing flow from the higher pressure port 1 or 3 to port 2, ensuring efficient management of hydraulic fluid in complex systems. The LS10-30-0-N features rapid response to load direction changes and fits an industry-common cavity, making it versatile for various hydraulic applications. This valve is robust with a pressure rating of up to 3500 psi and can handle operating fluid temperatures ranging from -40°C to +100°C with Buna N seals, -26°C to +204°C with fluorocarbon seals, and -54°C to +107°C with polyurethane seals. The maximum internal leakage is minimal at just 5 drops per minute at 3000 psi, highlighting its efficiency in maintaining system integrity. It also supports a wide range of fluid viscosities from 7.4 to 420 cSt and can operate effectively within a maximum contamination level as specified by ISO 4406 standards. Designed for easy installation, the LS10-30-0-N uses the VC103 cavity and can be installed with a torque ranging from 24 to 26 ft-lb. There are no orientation restrictions for installation, providing flexibility in system design. Additionally, corrosion protection is robust, offering resilience up to 960 hours of salt spray per ASTM B117 standards. Accessories such as seal kits (SK103XMM) and installation instructions are available for this model, alongside compatible housings like the 103W valve bodies that further enhance its application potential across various hydraulic systems.
