HYDRAFORCE
5200560

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5200560 (5200560) is a screw-in, cartridge-style hydraulic check valve designed primarily for use as a blocking or load-holding device. This model, known specifically as the CV0820, facilitates hydraulic flow from port 1 to port 2 while normally preventing flow in the opposite direction. Its operation hinges on a fully guided check which remains spring-biased closed until enough pressure is exerted at port 1 to compel opening towards port 2. The CV0820 is distinguished by its hardened seat which ensures both an extended life span and minimal leakage, enhancing the overall efficiency and reliability of the system in which it is installed. Additionally, it offers optional bias springs that provide flexibility for backpressure applications, catering to varying operational requirements. The compact size of the CV0820 enables easy integration into space-constrained areas while maintaining fast closing and seating times, crucial for systems requiring rapid response to changes in pressure or flow conditions.
