HYDRAFORCE
5110548

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce PV08-30B-6T-N-12ER (Material Number: 5110548) is a solenoid-operated, pressure-compensated, spool-type, normally closed, priority-type proportional flow control regulator. This versatile component can also function as a restrictive type, two-way pressure compensated proportional flow regulator when port 2 is blocked. The valve regulates priority flow from port 1 to port 3, maintaining consistent flow rates proportional to the current applied to the solenoid regardless of system working pressure. Excessive flow is bypassed through port 2 and can be utilized for auxiliary functions. In applications where the restrictive mode is needed, port 2 must be blocked to ensure the flow rate out of port 3 remains constant despite varying loads at port 3. The PV08-30B-6T-N-12ER features excellent linearity and hysteresis characteristics thanks to its hardened spool and cage construction, ensuring long-term durability. It supports various coil voltages and terminations with efficient wet-armature construction. The valve operates under a maximum pressure rating of 241 bar (3500 psi) at the inlet and up to 207 bar (3000 psi) for regulated and bypass conditions. It has a proof pressure capability of up to 345 bar (5000 psi) and burst pressure resistance up to 896 bar (13000 psi). For operational flexibility, it accommodates fluid temperatures ranging from -40\u00b0C to +100\u00b0C with Buna N seals or -26\u00b0C to +204\u00b0C with fluorocarbon seals. The PV08-30B-6T-N-12ER supports mineral-based or synthetic hydraulic fluids with lubricating properties within a viscosity range of 7.4 to 420 cSt. It also meets an operating contamination level of ISO 4406 class 20/18/14 standards and offers corrosion protection for up to 960 hours in salt spray conditions per ASTM B117 standards.
