HYDRAFORCE
5069072

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce SV16-22M-12T-N-12DS (5069072) is a solenoid-operated, 2-port, normally closed poppet-type hydraulic cartridge valve specifically designed for applications requiring load-holding or blocking with minimal internal leakage. In its de-energized state, this valve acts as a check valve, permitting flow from port 1 to port 2 while preventing flow in the reverse direction. When energized, the poppet lifts to allow bidirectional flow between ports. It features a continuous-duty rated coil and a hardened seat for durability and reduced leakage. The valve offers optional coil voltages and terminations, efficient wet-armature construction, and interchangeable voltage cartridges. It also includes a manual override option and an optional waterproof E-Coil rated up to IP69K for enhanced environmental protection. The SV16-22M-12T-N-12DS is built with steel featuring hardened work surfaces and zinc-plated exposed surfaces for added durability. Designed to fit industry-common VC16-2 cavities, it supports various seal options including buna-n, fluorocarbon, and polyurethane seals to accommodate different operating fluid temperatures ranging from -50\u00b0C to 205\u00b0C (-60\u00b0F to 400\u00b0F). The pressure rating stands at 241 bar (3500 psi), with maximum internal leakage limited to 3 drops per minute at full pressure. This valve is compatible with 10 size D and E coils and comes with available housings for installation flexibility.
