HYDRAFORCE
5061030

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5061030 (5061030) is a solenoid-operated, 2-port, normally closed, poppet-type, screw-in hydraulic cartridge valve. It is specifically designed to function as a load-holding or blocking valve in applications that demand low internal leakage. In its de-energized state, the SV16-22 operates as a check valve, permitting flow from port 1 to port 2 while preventing flow from port 2 to port 1. When energized, the poppet lifts to allow flow from port 2 to port 1 and continues to permit flow from port 1 to port 2. The valve features a continuous-duty rated coil and a hardened seat for enhanced durability and minimal leakage. It offers optional coil voltages and terminations for versatile use. The efficient wet-armature construction ensures reliable performance, while the unitized molded coil design enhances durability. For applications requiring manual intervention, an override option is available. Additionally, the optional waterproof E-Coils are rated up to IP69K for high-pressure wash-down environments. The cartridge design is voltage interchangeable and fits an industry-common cavity, making it adaptable for various systems and applications requiring robust load-holding capabilities with minimal leakage.
