HYDRAFORCE
5061012V

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5061012V (5061012V) is a solenoid-operated, 2-way, normally open, poppet-type hydraulic cartridge valve. It is engineered to function as a load-holding or blocking valve in applications that require low internal leakage. In its de-energized state, the SV16-21 poppet lifts to allow flow from port 2 to port 1 while severely restricting flow from port 1 to port 2. When energized, the valve closes the port 2 to port 1 flow path and acts as a check valve, permitting flow from port 1 to port 2 once the solenoid force is overcome, requiring between 50 to 100 psi (3.4 to 6.9 bar). This cartridge valve features a continuous-duty rated coil and a hardened seat for longevity and minimal leakage. It offers optional coil voltages and terminations along with an efficient wet-armature construction. The cartridges are voltage interchangeable, with a unitized molded coil design available with manual override options. Additionally, optional waterproof E-Coils are available, rated up to IP69K for robust protection against environmental factors. The valve fits an industry-common cavity for ease of integration into existing systems.
