HYDRAFORCE
5061009

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5061009 (5061009) is a solenoid-operated, 2-way, normally open, poppet-type, screw-in hydraulic cartridge valve. It is engineered to function as a load-holding or blocking valve in applications that require low internal leakage. In its default state, when de-energized, the SV16-21 poppet lifts to open the flow path from port 2 to port 1, while flow from port 1 to port 2 remains significantly restricted. Upon energization, the valve closes the flow path from port 2 to port 1 and functions as a check valve, permitting flow from port 1 to port 2 after overcoming a solenoid force requiring between 50 to 100 psi (3.4 to 6.9 bar). This product features a continuous-duty rated coil and a hardened seat for enhanced durability and low leakage. It also offers optional coil voltages and terminations along with an efficient wet-armature construction. The cartridges are voltage interchangeable and come with a unitized, molded coil design. Additional options include a manual override feature and waterproof E-Coils that are rated up to IP69K for robust environmental protection. The valve fits into an industry-common cavity, making it versatile for various hydraulic applications demanding reliable load-holding capabilities.
