HYDRAFORCE
5048153

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5048153 (5048153) is a solenoid-operated, 2-position, 4-way, direct-acting spool-type, screw-in hydraulic cartridge valve designed for precision and durability in hydraulic systems. This model serves as a selector valve in selector or series-parallel drive circuits, facilitating efficient control over fluid direction and flow. In its default state when de-energized, the SVX model allows bidirectional flow between port 1 and port 2, as well as between port 3 and port 4, while blocking flow at ports 5 and 6. Upon energization, the spool shifts to enable bidirectional flow between ports 1 and port 3 and between ports 2 and port 4, with ports 5 and port 6 remaining blocked. This valve features hardened precision components including a spool and cage which ensure longevity even under rigorous conditions. It is engineered to handle all ports being fully pressurized without compromise to performance. The heavy-duty waterproof E-Coils integrated into the design are rated up to IP69K, offering high-level protection against ingress of dust and high-temperature high-pressure water jets. This robust external metal-shell coil design enhances the valve's resilience in challenging environments. Optional coil voltages and terminations provide additional flexibility for various operational requirements making the Hydraforce SVX an adaptable solution for diverse hydraulic applications.
