HYDRAFORCE
5048000

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce SV12-60-0-N-00 (5048000) is a solenoid-operated, 2-position, 4-way, direct-acting spool-type, screw-in hydraulic cartridge valve designed for use as a selector valve in selector or series-parallel drive circuits. This robust valve allows bidirectional flow between ports, facilitating various hydraulic functions. When deenergized, it enables flow between port 1 and port 2, and between port 3 and port 4 while blocking flow at ports 5 and 6. Conversely, when energized, the spool shifts to allow flow between port 1 and port 6 and between port 3 and port 4 while blocking ports 2 and 5. Key features of the SV12-60-0-N-00 include hardened precision spools and cages ensuring longevity even under rigorous conditions. All ports can be fully pressurized which enhances its versatility in different hydraulic setups. It is equipped with heavy-duty waterproof E-Coils rated up to IP69K standards that provide reliable performance in wet or dusty environments. The external metal-shell coil design adds an extra layer of durability. The valve’s specifications include a range of operating temperatures from -40°C to +100°C with Buna N seals or up to +120°C with Viton seals. It supports mineral-based or synthetic hydraulic fluids with lubricating properties within a viscosity range of 7.4 to 420 cSt. The SV12-60-0-N-00 can handle pressures up to around bar (psi), proof pressures substantially higher to ensure safety and reliability, and burst pressures that confirm its capability to withstand extreme conditions. This valve is designed for ease of installation in standard cavities (VC10-4) without orientation restrictions, ensuring flexibility across various applications. Its cycle life extends up to one million cycles at rated pressure and flow, highlighting its durability for long-term industrial use.
