5044822

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce HSP12-47H-0-U-00 (5044822) is a high-performance, proportional cartridge valve designed for precise hydraulic control. This spool-type, screw-in, cartridge-style hydraulic solenoid valve is engineered to manage flow with high precision in various hydraulic systems. When de-energized, it blocks flow to one port while allowing free flow between other ports through a bleed orifice. Upon energization of the S coil, it enables directional flow between specified ports, making it adaptable for applications where work port flows are unequal due to cylinder ratios. This valve features manual override options that allow for emergency operation or testing without electrical power. Its construction includes a continuous-duty rated coil and efficient wet-armature design that ensures reliable performance even under rigorous conditions. The valve's E-Coils are rated up to IP69K, offering excellent protection against ingress of dust and high-temperature, high-pressure washdowns. Rated for pressures up to several hundred bar and capable of handling up to one million cycles, the HSP12-47H-0-U-00 is built for durability and longevity. It supports a wide range of fluid temperatures from -40°C to 120°C depending on the seal material used (Buna N, Fluorocarbon, or Urethane), ensuring versatility across different environmental conditions. The valve's design allows it to be used with mineral-based or synthetic hydraulic fluids with lubricating properties within a viscosity range of 7.4 to 420 cSt. Additionally, its maximum operating contamination level is compliant with ISO standards, which helps maintain system integrity and reduces maintenance needs. Overall, the Hydraforce HSP12-47H-0-U-00 offers robust performance and reliability for sophisticated hydraulic applications requiring precise flow control and manipulation under varying operational conditions.
