HYDRAFORCE
5042638
$325.50 USD
- HYDRAFORCE
- Material:5042638
- Model:SV12-40R-12T-N-12ER/Z SOLENOID VALVE
- Summary:SOLENOID VALVE SPOOL, 2 POSITION, 4 PORT
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5042638 (5042638) is a solenoid operated, 2-position, 4-way, direct-acting spool type, screw-in hydraulic cartridge valve designed for robust performance in hydraulic systems. This valve efficiently manages the direction of the fluid flow within hydraulic circuits. When de-energized, the SVR configuration allows flow from port 1 to port 2 and from port 3 to port 4. Upon energization, the spool shifts to enable flow from port 1 to port 4 and from port 3 to port 2. The design includes a continuous-duty rated coil and features a hardened precision spool and cage that enhance its durability and lifespan. Additionally, the Hydraforce 5042638 offers flexibility with optional coil voltages and terminations to accommodate various operational requirements. A manual override option is available for situations requiring manual control of the valve. All ports on this valve are capable of being fully pressurized, making it versatile for different hydraulic applications. For environments requiring rugged components, this model comes equipped with heavy-duty waterproof E-Coils rated up to IP69K, ensuring reliable performance even in harsh conditions. This valve is particularly suitable for applications demanding reliable fluid control such as in mobile hydraulics and industrial machinery systems.
The Hydraforce 5042638 (5042638) is a solenoid operated, 2-position, 4-way, direct-acting spool type, screw-in hydraulic cartridge valve designed for robust performance in hydraulic systems. This valve efficiently manages the direction of the fluid flow within hydraulic circuits. When de-energized, the SVR configuration allows flow from port 1 to port 2 and from port 3 to port 4. Upon energization, the spool shifts to enable flow from port 1 to port 4 and from port 3 to port 2. The design includes a continuous-duty rated coil and features a hardened precision spool and cage that enhance its durability and lifespan. Additionally, the Hydraforce 5042638 offers flexibility with optional coil voltages and terminations to accommodate various operational requirements. A manual override option is available for situations requiring manual control of the valve. All ports on this valve are capable of being fully pressurized, making it versatile for different hydraulic applications. For environments requiring rugged components, this model comes equipped with heavy-duty waterproof E-Coils rated up to IP69K, ensuring reliable performance even in harsh conditions. This valve is particularly suitable for applications demanding reliable fluid control such as in mobile hydraulics and industrial machinery systems.
Unit weight:
0.43 kg (0.95 lb)
Internal wetted surface area:
333 cm² (51.6 in²)
Ratings | Pressure Ratings Pressure rating: 241 bar (3500 psi) Proof pressure: 345 bar (5000 psi) Burst pressure: 758 bar (11000 psi) Flow Ratings Maximum internal leakage: 410 ml/min (25 in³/min) Max at 240 bar (3500 psi) Temperature Ratings Operating fluid temperature: -40 to 100 °C (-40 to 212 °F) With buna N seals -26 to 204 °C (-15 to 400 °F) With viton seals -54 to 107 °C (-65 to 225 °F) With polyurethane seals Storage temperature: -40 to 70 °C (-40 to 160 °F) Ambient temperature: -40 to 70 °C (-40 to 160 °F) Other Ratings Environmental rating: Ip67 (with integral connectors) |
Operating Parameters | Fluids:
Mineral based or synthetic hydraulic fluid with lubricating properties Fluid viscosity range: 7.4 to 420 cSt Maximum operating contamination level: 20/18/14 per ISO 4406 |
Performance | |
Installation Specifications | Cavity:
VC12-4 12-size-4-way Cavities Cartridge installation torque: 70.5 to 81.3 N-m (52 to 60 ft-lb) Coil nut torque: 6.8 to 9.5 N-m (5 to 7 ft-lb) Orientation restriction: None |
Order Code | POSITION CODE DESCRIPTION SV12-40RE-H-J-L E Manual Override E BLANK NONE E K Momentary Push Override, Knob E P Momentary Push Override, Button E T Variable Position Override, Slotted Screw H Line Body H 0 No Body H 10T Aluminum SAE 10 H 12T Aluminum SAE 12 H 12TD Ductile Iron SAE 12 H 6B Aluminum BSPP 3/4" (6) J Seal J N Buna-N J V Fluorocarbon J P Polyurethane J U PPDI Urethane L Coil L 0 No Coil L 12EG 12 VDC, E-Coil, DIN 43650 L 12EL 12 VDC, E-Coil, Dual Lead Wires L 12EL/W 12 VDC, E-Coil, Dual Lead Wires with WeatherPak L 12ER 12 VDC, E-Coil, Deutsch L 12ER/Z 12 VDC, E-Coil, Deutsch with Zener Diode L 12ES 12 VDC, E-Coil, Dual Spade L 12EY 12 VDC, E-Coil, Metri-Pack 150 L 24EG 24 VDC, E-Coil, DIN 43650 L 24ER 24 VDC, E-Coil, Deutsch L 24ER/Z 24 VDC, E-Coil, Deutsch with Zener Diode L 24ES 24 VDC, E-Coil, Dual Spade |
Seal kit:
SK12-4X-MMM
X=seal option
Seal kit installation instructions
Housings:
Available
12-4w valve bodies
Coils:
12 size E
coils
