HYDRAFORCE
5022250

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5022250 (5022250) is a solenoid-operated, direct acting, 3-position, 4-way, closed center spool, proportional directional control valve. This precision-engineered valve is designed as a screw-in hydraulic cartridge for use with general-purpose hydraulic fluids. It features a sophisticated design that allows for multiple flow directions based on the energization of its coils. Specifically, when deenergized, the SP1047CX configuration blocks flow to all ports; energizing coil 1 permits flow from port 3 to port 4 and from port 2 to port 1, while energizing coil 2 changes the flow from port 3 to port 2 and from port 4 to port 1. This model boasts a continuous-duty rated solenoid and includes a hardened precision spool and cage which enhance its durability and lifespan. The valve offers flexibility with optional coil voltages and terminations along with an optional manual override feature. For environments requiring robust protection against water ingress, waterproof E-Coils rated up to IP69K are available as an option. Its efficient wet-armature construction helps maintain good linearity and hysteresis performance. Designed for versatility in installation and application, the cartridges are voltage interchangeable and fit an industry-common cavity. This makes the Hydraforce 5022250 an excellent choice for various hydraulic system applications requiring reliable directional control of fluid flow within a compact design framework.
