HYDRAFORCE
5015003

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5015003 (5015003) is a high-performance hydraulic cartridge valve designed for precise control in fluid power applications. This solenoid-operated, direct-acting valve features a 5-port, 3-position spool configuration, making it versatile for various hydraulic circuits. The integral load sense port enhances its functionality by providing real-time feedback on pressure changes, ensuring efficient operation and energy conservation. The operation of the SV0858DX model is straightforward yet effective. In its default state when de-energized, it blocks the inlet flow at port 5 while venting the load sense port 1 to port 3, and connecting ports 2 and 4 to port 3. Energizing coil s1 changes the flow path allowing fluid from port 5 to port 2 and from port 4 to port 3. Similarly, activating coil s2 permits flow from port 5 to port 4 and from port 2 to port 3. This flexibility in flow direction supports a wide range of machinery actions and responses. Key features of this model include a continuous-duty rated solenoid for reliable performance even under strenuous conditions. The hardened precision spool and cage ensure durability and longevity of the valve even in demanding environments. The SV0858DX offers optional coil voltages and terminations to accommodate different electrical requirements, along with waterproof E-Coils that are rated up to IP69K for superior protection against dust and water ingress. Additionally, its efficient wet-armature construction minimizes power loss, enhancing overall operational efficiency. The compact size of this unit allows for easier installation and integration into various hydraulic systems without requiring excessive space. With interchangeable voltage cartridges and a unitized molded coil design, the Hydraforce SV0858DX provides both flexibility and ease of maintenance, making it an ideal choice for sophisticated hydraulic systems requiring robust control solutions.
