HYDRAFORCE
5010819

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5010819 (5010819) is a solenoid-operated, 2-way, normally open, poppet-type, screw-in hydraulic cartridge valve. This valve is particularly designed to function as a load-holding or blocking valve in various applications that require low internal leakage at high pressures. Its operational mechanism includes a poppet that lifts to open from port 2 to port 1 when de-energized, allowing flow also from port 1 to port 2. Conversely, when energized, the cartridge acts as a check valve, effectively blocking flow from port 2 to port 1 after overcoming the solenoid force which requires between 50 to 150 psi (3.4 to 10.3 bar). Among its notable features are a continuous-duty rated coil and a hardened seat which ensures long life and minimal leakage. The unit offers optional coil voltages and terminations making the cartridges voltage interchangeable. It also boasts a unitized, molded coil design with a manual override option and optional waterproof E-Coils rated up to IP69K for enhanced durability and performance in harsh conditions. Additionally, it features corrosion-resistant plating and maintains an industry common compact size for easy integration into various systems.
