HYDRAFORCE
5009400

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5009400 (5009400) is a solenoid-operated, 2-way, poppet type, normally open, screw-in hydraulic cartridge valve. It is specifically designed for low leakage in load-holding applications. This model operates by lifting the SV0823X poppet to open flow from port 2 to port 1 when de-energized; flow is similarly open from port 1 to port 2 in this state. When energized, the valve acts as a check valve allowing flow from port 1 to port 2 while blocking flow from port 2 to port 1 after overcoming the solenoid force which requires between 50 to 150 psi (3.4 to 10.3 bar). Key features of the Hydraforce 5009400 include a continuous-duty rated coil and a hardened seat that ensures long life and maintains low leakage. It offers optional coil voltages and terminations, making the cartridges voltage interchangeable. The unitized, molded coil design enhances durability and reliability of operation. Additionally, it provides a manual override option and an optional waterproof E-Coils rated up to IP69K for enhanced protection against environmental factors. The compact size of this valve along with its industry common cavity makes it versatile for various hydraulic systems requiring precise flow control and reliable load holding capabilities.
