HYDRAFORCE
5008834

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5008834 (5008834) is a solenoid-operated, 2 position, 6 way, direct acting, spool-type, screw-in hydraulic cartridge valve designed for robust hydraulic system applications. This valve is engineered to control the direction of flow in hydraulic systems effectively. In its de-energized state, the SV8061 configuration of the valve blocks flow to ports 5 and 6 while facilitating flow between ports 4 and 3, as well as between ports 1 and 2. Conversely, when energized, the spool shifts to block flow to ports 2 and 3 and allows flow between ports 4 and 5, and between ports 1 and 6. This functionality makes it particularly useful in circuits where the valve acts as a selector directing flow between two cylinders with unequal area ratios. For optimal performance in such setups, it is recommended that cylinder head sides be connected to ports 3 and 5, with rod sides connected to ports 2 and 6. The Hydraforce 5008834 boasts a hardened precision spool and cage which ensures long life even under demanding conditions. It also features optional coil voltages and terminations tailored to various operational needs. The heavy-duty waterproof E-Coils are rated up to IP69K, indicating high resistance against ingress of dust and high-temperature water jets. Additionally, these coils are continuous-duty rated ensuring reliability through prolonged use. The cartridges are designed for voltage interchangeability allowing for flexible application across different systems. This combination of durability, adaptability, and precise control makes the Hydraforce 5008834 an essential component for advanced hydraulic system configurations.
