HYDRAFORCE
5008814

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce SV80-61-6T-N-12DR (5008814) is a solenoid-operated, 2-position, 6-way, direct-acting, spool-type, screw-in hydraulic cartridge valve designed for versatile flow control in hydraulic systems. This model features a precision-hardened spool and cage that ensure long life and reliability under various operating conditions. The valve operates by blocking flow to specific ports depending on its energized or de-energized state: when de-energized, it blocks flow to ports 5 and 6 while allowing flow between ports 4 and 3, as well as between ports 1 and 2; when energized, it shifts to block flow to ports 2 and 3 and allows flow between ports 4 and 5, and between ports 1 and 6. This configuration makes the SV80-61-6T-N-12DR particularly suitable for applications where selective directional control of fluid is required, such as in circuits used as selectors directing flow between two cylinders with unequal area ratios. For optimal performance in such setups, cylinder head sides should be connected to ports 3 and 5 while rod sides connect to ports 2 and 6. The valve is engineered for robust performance with features like heavy-duty waterproof E-Coils rated up to IP69K for maximum protection against dust ingress and high-pressure water jets. These coils are continuous-duty rated and voltage interchangeable which provides flexibility across different installations. The valve operates effectively within a fluid temperature range of -40°C to +100°C with Buna N seals or up to +204°C with Viton seals. For installation ease, the SV80-61-6T-N-12DR fits into a VC106 cavity with no orientation restrictions on cartridge installation. It can handle pressures up to 207 bar (3000 psi) with maximum internal leakage specified at less than 246 ml/min at this maximum pressure. This unit's compact design weighs just about 0.18 kg (0.4 lb) making it easy to integrate into various hydraulic systems without significant spatial constraints.
