HYDRAFORCE
5008509

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5008509 (5008509) is a solenoid-operated, 4-port, 3-position, direct-acting spool type screw-in hydraulic cartridge valve designed for efficient control in hydraulic systems. This valve offers versatility in its operations; when de-energized, it blocks cylinder ports while allowing flow from port 3 to port 1. Energizing coil 1 shifts the flow from port 3 to port 2 and from port 4 to port 1. Similarly, activating coil 2 changes the flow direction from port 3 to port 4 and from port 2 to port 1. This functionality makes it suitable for applications where work port flows are unequal due to cylinder ratios, directing higher return flows preferably through port 2. The model boasts several features enhancing its performance and reliability. It has a continuous-duty rated solenoid and a hardened precision spool and cage which ensure long service life even under rigorous conditions. The valve is available with optional coil voltages and terminations, providing adaptability for various electrical requirements. A manual override option offers additional operational flexibility. For environments requiring robust durability, optional waterproof E-Coils rated up to IP69K are available, ensuring protection against ingress of dust and high-temperature high-pressure water jets. Moreover, the SV0847AX exhibits efficient wet-armature construction and allows all ports to be fully pressurized which enhances its effectiveness in hydraulic circuit applications. The cartridges are voltage interchangeable which simplifies maintenance and replacement processes. Its unitized, molded coil design alongside an industry-common cavity ensures easy integration into existing systems without extensive modifications. Compact in size, this valve is particularly suitable for applications where space is at a premium but powerful performance is required.
