HYDRAFORCE
5006873

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce SV08-35-0-N-12ER (5006873) is a high-performance solenoid-operated hydraulic valve designed for precise fluid control in various applications. This direct-acting, spool-type valve operates in two positions and manages flow across three ports. In its default state when de-energized, it blocks flow at port 1 while enabling flow from port 2 to port 3. Upon activation, the spool shifts to allow flow from port 2 to port 1 and blocks flow at port 3. Crafted for durability and reliable operation, the SV08-35 features a hardened precision spool and cage which enhance its lifespan under continuous use. Its coil is rated for continuous duty, and the unit boasts an efficient wet-armature construction. The design accommodates interchangeable voltage cartridges, allowing flexibility across different systems with varying electrical requirements. The valve's compact size and industry-standard cavity (VC083) make it suitable for integration into a wide range of equipment without extensive modification. It offers manual override options and can be equipped with waterproof E-Coils rated up to IP69K for operation in harsh environments. The valve's specifications include a maximum operating pressure of 207 bar (3000 psi), with proof pressure up to 241 bar (3500 psi) and burst pressure reaching up to 620 bar (9000 psi). It supports a broad temperature range from -40°C to +100°C (-40°F to +212°F) depending on seal material, ensuring versatility across different operational climates. This model is ideal for applications requiring robust control of hydraulic flows with the option for manual adjustments in critical situations or system configurations that need waterproofing capabilities.
