HYDRAFORCE
5003919

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce SP10-47D-0-N-24DR (5003919) is a high-performance solenoid-operated, direct acting, 3-position, 4-way motor spool proportional directional control valve. This screw-in hydraulic cartridge valve is designed for use with general-purpose hydraulic fluids. The SP10-47D-0-N-24DR features a unique configuration that allows it to block flow to port 3 while permitting flow from ports 2 to 1 and from port 4 to 1 when deenergized. Energizing coil 1 changes the flow path allowing fluid movement from port 3 to port 4 and maintaining the flow from port 2 to port 1. Similarly, activating coil 2 permits fluid flow from port 3 to port 2 and from port 4 to port 1. This model boasts a continuous-duty rated solenoid and exhibits hardened precision for the spool and cage, enhancing its longevity and reliability in various applications. Its design includes optional waterproof E-Coils rated up to IP69K, ensuring optimal performance even in harsh environmental conditions. The valve accommodates various coil voltages and terminations, providing flexibility for different system requirements. Additionally, it offers manual override options and features efficient wet-armature construction. The SP10-47D-0-N-24DR operates effectively within a hydraulic pressure range up to 250 bar (3625 psi) with a proof pressure of up to 345 bar (5000 psi) and can handle burst pressures as high as 827 bar (12000 psi). It supports maximum flow rates up to approximately six gallons per minute (22.7 liters per minute), depending on specific configurations like manual overrides. This valve is engineered for precise control with good linearity and minimal hysteresis reported at about ten percent under specific conditions. Its robust design ensures reliable operation across a broad range of temperatures making it suitable for diverse operating environments characterized by varying thermal conditions.
