HYDRAFORCE
5003616

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5003616 (5003616) is a solenoid operated, direct acting, 3 position, 4-way, closed center spool, proportional directional control valve. Designed as a screw-in hydraulic cartridge valve, it is optimized for use with general purpose hydraulic fluids. This model features a hardened precision spool and cage that enhance its durability and lifespan. The SP1047CX configuration of the valve ensures that when de-energized, it blocks flow to all ports. However, upon energization of coil 1, the flow is directed from port 3 to port 4 and from port 2 to port 1. Energizing coil 2 reverses this flow from port 3 to port 2 and from port 4 to port 1. Notably, while port 1 can be fully pressurized, it is not intended for use as the valve's inlet. This valve includes several noteworthy features such as continuous-duty rated solenoids and efficient wet-armature construction which contribute to its reliable performance in various applications. Additional options available for this model include different coil voltages and terminations, manual override capabilities, and waterproof E-Coils that are rated up to IP69K for enhanced protection against dust and high-temperature high-pressure wash downs. This versatility coupled with good linearity and hysteresis properties makes the Hydraforce 5003616 an effective solution for directional control in hydraulic systems across multiple applications where precise fluid control is essential. The industry-common cavity design also facilitates easier integration or replacement in existing systems.
