HYDRAFORCE
5001026

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5001026 (5001026) is a solenoid-operated, 2-way, normally open, poppet type, screw-in hydraulic cartridge valve. This model is specifically designed for low leakage in load-holding applications, making it an ideal choice for situations where maintaining control over fluid flow is critical. The SV0821 model operates by allowing flow from port 2 to port 1 when de-energized; however, flow from port 1 to port 2 is significantly restricted under these conditions. Once energized, the valve's poppet closes against its seat effectively blocking the flow from port 2 to port 1. To enable flow from port 1 to port 2, the solenoid force must be overcome. This cartridge valve features a continuous-duty rated coil and a hardened seat which ensure long life and maintain low leakage rates. It offers flexibility with optional coil voltages and terminations while maintaining interchangeability across different voltage cartridges. The unitized, molded coil design enhances durability and reliability of the valve system. Additionally, there is an option for a manual override and waterproof E-Coils that are rated up to IP69K for enhanced operational resilience in various environments. Its industry common cavity design facilitates compatibility with existing systems while its compact size allows for easier installation in space-constrained applications.
