HYDRAFORCE
5000073

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 5000073 (5000073) is a solenoid-operated, 2-way, normally closed, piloted poppet-type, screw-in hydraulic cartridge valve designed primarily to function as a blocking or load-holding device for low flow circuits. This valve operates as a check valve when de-energized, permitting hydraulic fluid to flow from port 1 to port 2 and blocking the flow in the reverse direction. Upon energization, the poppet lifts to facilitate flow from port 2 to port 1, though it restricts flow from port 1 to port 2 significantly. Key features of the Hydraforce 5000073 include a continuous-duty rated coil and a hardened seat that ensures long life and minimal leakage. The unit offers optional coil voltages and terminations, making it versatile for different electrical requirements. The cartridges are voltage interchangeable which provides flexibility in system design. The valve also boasts a unitized, molded coil design enhancing its durability and reliability. Additionally, the model is equipped with optional waterproof E-Coils that are rated up to IP69K for high-level protection against ingress of dust and water, making it suitable for harsh environments. It also features corrosion-resistant plating that withstands up to 960 hours of salt spray per ASTM B117 standards, ensuring extended service life in corrosive settings. The compact size of this valve along with an industry common cavity allows for easier installation and compatibility with various systems. This combination of robust construction and flexible operational characteristics makes the Hydraforce 5000073 an efficient solution for controlling fluid flow in hydraulic systems across numerous applications.
