HYDRAFORCE
5000008

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce SV08-20-0-N-00 (5000008) is a solenoid-operated, 2-way, normally closed, poppet-type, screw-in hydraulic cartridge valve. Designed primarily for low flow circuits, this valve serves as a blocking or load-holding device with pull-only manual override capabilities suitable for handles or cable linkage systems. In its default state when de-energized, the SV08-20-0-N-00 functions as a check valve allowing fluid flow from port 1 to port 2 while preventing flow in the reverse direction. Upon energization, the valve's poppet lifts to facilitate an open flow path from port 1 to port 2, concurrently restricting flow from port 2 to port 1. This model boasts several key features enhancing its functionality and durability: it has a continuous-duty rated coil and a hardened seat which ensures long life and minimal leakage. It offers flexibility with optional coil voltages and terminations; cartridges that are voltage interchangeable add further versatility. The unitized, molded coil design aids in robust performance while the compact size allows for easier installation in space-constrained applications. Additionally, it includes a manual override option and fits an industry common cavity, making it an adaptable solution for various hydraulic system requirements.
