HYDRAFORCE
4208230

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce ECDR-0203A-001 (4208230) is a sophisticated electronic controller designed to operate solenoid-controlled proportional valves efficiently. This device incorporates a powerful bit processor, enhancing its capability to handle complex calculations swiftly. It is equipped with three versatile inputs that can be adjusted to various configurations ranging from digital to analog, catering to a broad spectrum of control needs. Additionally, the ECDR-0203A-001 features two PWM outputs with an adjustable frequency that allows for precise control over connected devices. The unit’s connectivity is bolstered by a single CAN bus interface supporting both CANopen and SAE J1939 communication protocols, making it highly adaptable in various technological environments. A distinctive feature of this controller is its red-green LED signal, which provides immediate visual feedback on the system's status, aiding in quick diagnostics and monitoring. Designed with durability in mind, it has a molded enclosure with a scratch-resistant finish ensuring longevity and reliability in challenging conditions. The ECDR-0203A-001 can be configured using the HFImpulse software, which is an intuitive, web-accessible tool that simplifies setting adjustments and device configuration. This controller is particularly useful in applications such as transmission controls, vehicle traction controls, joystick controls, and harvesting function controls. It offers enhanced diagnostic features including internal checks for over/under voltage conditions and coil failure. Moreover, it includes short-circuit protection for outputs and has safety measures like automatic resetting to a safe mode if supply voltage falls below or exceeds set thresholds. This makes the ECDR-0203A-001 not only a versatile tool in managing hydraulic functions but also a robust solution ensuring operational safety and efficiency.
