Hydraforce-4002768-4002768

HYDRAFORCE
4002768


$711.00 USD
  • HYDRAFORCE
  • Material:4002768
  • Model:ECAN-1 WIRELESS CAN INTERFACE
  • Summary:Wireless CAN bus interface

Quantity in stock: 0

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hydraforce directly.***
The Hydraforce 4002768 (4002768) is a versatile ECAN multifunctional wireless CAN interface equipped with an integrated antenna, designed to enhance connectivity and data management within vehicle or machinery systems. This compact device enables users to access CAN data in various modes, including functioning as a wireless interface or a CAN to CAN bridge. When operating in interface mode, the ECAN facilitates the transmission of CAN data to WLAN devices such as PCs, supporting both HFImpulse and CoDeSys configuration software for efficient setup and management. Additionally, its capability as a CAN to CAN bridge allows for the wireless transmission of CAN data between two ECAN units. This feature is particularly useful in scenarios where replacing traditional CAN cables is necessary, such as in drag chains or with remote control units, thereby simplifying installation and reducing cable clutter. The rugged design of the ECAN includes an IP-rated enclosure that ensures durability and resistance to impacts and moisture, making it suitable for outdoor hydraulic equipment applications. Its compact size further enhances its applicability in environments where space is at a premium yet high performance is demanded.

Electrical Parameters
Supply voltage: 8 to 32 Vdc

Memory: 1024 kB/16kB

Properties
Unit weight: 0.06 kg (0.13 lb)

Enclosure material: ULTRAMID® C3U BK 23079 PA6/66 FR

Connectors: M12 5-pin
(mates with M12 A-coded 5-pin female)

Diagnostic indicator: Bi-color red/green LED

Environmental Ratings
Ingress protection class: IP67
With all connectors plugged in or suitably capped

Network
CAN interface: ISO 11898-2 HIGH SPEED, 2.0 A/B

WLAN: IEEE 802.11 A/B/G/N, IEEE 802.11 D/E/I/H, DUAL BAND: 2.4 GHz / 5
GHz

WLAN Security: WPA2-PSK, WPA-PSK, WEP64, WEP128, PEAP

WLAN Range: 75 m (250 ft)

Certifications: CE, FCC, E1
THE DEVICE DOES NOT COMPLY WITH DIRECTIVE 2014/34/EU AND MUST THEREFORE
NOT BE USED IN POTENTIALLY EXPLOSIVE ENVIRONMENTS. FOR DETAILED
SPECIFICATIONS

https://www.hydraforce.com/globalassets/product-images/ecan-1_dim2022-02-24.gif


ECAN-1: Part No. 4002768 Mating connector: M12 A-coded Part No. 4001953

Product PDF File Download Product PDF File
