The Flextral VT300-32 (VT300-32) is a high-performance hydraulic hose that is designed to meet or exceed the rigorous requirements of SAE 100R13. It features a robust construction with a nitrile tube and six spirals of high-tensile steel wire reinforcement, making it suitable for very high-pressure applications. The outer cover of the hose is made from synthetic rubber, which is not only highly abrasion-resistant but also meets MSHA fire-resistant standards. With an internal diameter of 2 inches and an outer diameter of approximately 71.10 mm, the VT300-32 provides a maximum working pressure of 5000 psi and a minimum burst pressure of 20000 psi. This makes it an excellent choice for demanding hydraulic systems utilizing petroleum-based, polyolester, or water-glycol based fluids. The hose's flexibility is highlighted by its minimum bend radius of 420 mm, which is less than standard spiral hoses, allowing for easier installation and routing in tight spaces. The VT300-32 is also notable for its wide temperature range capability from -48°C to +121°C (-55°F to +250°F), ensuring reliable performance in various operating environments. This hose model comes in lengths ranging from a minimum of 12 inches up to a maximum of 1200 inches and is typically packaged in coils. Applications for this hose include a variety of hydraulic systems where high pressures and tough working conditions are prevalent. Additionally, it has been accepted for hydraulic service by SAE J1942/1 USCG H standards, further confirming its suitability for use in marine and offshore applications where such certifications are required.
The Flextral VT300-32 (VT300-32) is a high-performance hydraulic hose that is designed to meet or exceed the rigorous requirements of SAE 100R13. It features a robust construction with a nitrile tube and six spirals of high-tensile steel wire reinforcement, making it suitable for very high-pressure applications. The outer cover of the hose is made from synthetic rubber, which is not only highly abrasion-resistant but also meets MSHA fire-resistant standards. With an internal diameter of 2 inches and an outer diameter of approximately 71.10 mm, the VT300-32 provides a maximum working pressure of 5000 psi and a minimum burst pressure of 20000 psi. This makes it an excellent choice for demanding hydraulic systems utilizing petroleum-based, polyolester, or water-glycol based fluids. The hose's flexibility is highlighted by its minimum bend radius of 420 mm, which is less than standard spiral hoses, allowing for easier installation and routing in tight spaces. The VT300-32 is also notable for its wide temperature range capability from -48°C to +121°C (-55°F to +250°F), ensuring reliable performance in various operating environments. This hose model comes in lengths ranging from a minimum of 12 inches up to a maximum of 1200 inches and is typically packaged in coils. Applications for this hose include a variety of hydraulic systems where high pressures and tough working conditions are prevalent. Additionally, it has been accepted for hydraulic service by SAE J1942/1 USCG H standards, further confirming its suitability for use in marine and offshore applications where such certifications are required.
VT300 Exceeds 100R13
Meets or exceeds the requirements of SAE 100R13.
Tube: Nitrile
Reinforcement: Six spirals of high-tensile steel wire
Cover: Synthetic rubber, high-abrasion resistant, meets requirements of MSHA fire resistant standards Temperature: -48°C to +121°C (-55°F to +250°F)
Temperature: -48°C to +121°C (-55°F to +250°F)
Packaging: Coils
Application: VT300 is ideal for hydraulic systems with petroleum, polyolester, or water/glycol based fluids. The hose is very flexible with a bending radius less than standard spiral hose and a high-abrasion resistant cover. Hose is accepted for hydraulic service. SAE J1942/1 USCG – H accepted.
| PART NUMBER | HOSE I.D. | HOSE O.D. | MAX W.P. | MIN. BURST PRESSURE | MIN. BEND RADIUS | WEIGHT | ONE PIECE Skive | ||
|---|---|---|---|---|---|---|---|---|---|
| (in) | (in) | (mm) | (psi) | (psi) | (in) | (mm) | (lbs/ft) | COUPLINGS | |
| VT300-32 | 2 | 2.8 | 71.10 | 5000 | 20000 | 16.5 | 420.00 | 4.20 | coupling_VT300 |
