The Flextral PX350-12 (PX350-12) is a high-performance hydraulic hose designed for demanding applications. This model is part of the PX350 series and features a two-wire braid construction that meets or exceeds SAE 100R16 and EN857 2SC working pressure standards. The hose is built with an inner tube made from CPE (Chlorinated Polyethylene), and its reinforcement consists of two braids of high-strength steel wire, ensuring durability and long service life. The outer cover of the PX350-12 is crafted from blue, abrasion-resistant CPE, which is also MSHA approved, highlighting its suitability for challenging environments. With a hose ID of 1030, an outer diameter of 1.1 inches (28.00 mm), and a weight of 0.61 lbs/ft, this model combines robustness with ease of handling. It can withstand operating pressures up to 3500 psi with a minimum burst pressure of 14000 psi. Flexibility is another key feature, demonstrated by its minimum bend radius of 5 inches (127 mm), allowing for installation in tight spaces without compromising flow or performance. The PX350-12 is versatile in terms of length as well, available from a minimum length of 12 inches up to a maximum length of 1200 inches. This hose's temperature range extends from -40°C to +150°C (-40°F to +302°F), making it an excellent choice for systems that may experience extreme temperatures. Its compatibility with mineral and vegetable oils, water emulsions, compressed air, and inert gases further broadens its application scope across various hydraulic systems requiring reliable high-pressure performance.
The Flextral PX350-12 (PX350-12) is a high-performance hydraulic hose designed for demanding applications. This model is part of the PX350 series and features a two-wire braid construction that meets or exceeds SAE 100R16 and EN857 2SC working pressure standards. The hose is built with an inner tube made from CPE (Chlorinated Polyethylene), and its reinforcement consists of two braids of high-strength steel wire, ensuring durability and long service life. The outer cover of the PX350-12 is crafted from blue, abrasion-resistant CPE, which is also MSHA approved, highlighting its suitability for challenging environments. With a hose ID of 1030, an outer diameter of 1.1 inches (28.00 mm), and a weight of 0.61 lbs/ft, this model combines robustness with ease of handling. It can withstand operating pressures up to 3500 psi with a minimum burst pressure of 14000 psi. Flexibility is another key feature, demonstrated by its minimum bend radius of 5 inches (127 mm), allowing for installation in tight spaces without compromising flow or performance. The PX350-12 is versatile in terms of length as well, available from a minimum length of 12 inches up to a maximum length of 1200 inches. This hose's temperature range extends from -40°C to +150°C (-40°F to +302°F), making it an excellent choice for systems that may experience extreme temperatures. Its compatibility with mineral and vegetable oils, water emulsions, compressed air, and inert gases further broadens its application scope across various hydraulic systems requiring reliable high-pressure performance.
PX350 High-Temp. Two Wire Braid Hose
Meets or exceeds SAE 100R16 and EN857 2SC working pressures
Tube: CPE
Reinforcement: Two-braid high-strength steel-wire reinforcement
Cover: Blue, abrasion-resistant CPE MSHA approved cover
Temperature: -40°C to +150°C (-40°F to +302°F)
Packaging: Reels
Application: Suitable for use with mineral and vegetable oil, water emulsions, compressed air and inert gases.
| PART NUMBER | HOSE I.D. | HOSE O.D. | MAX W.P. | MIN. BURST PRESSURE | MIN. BEND RADIUS | WEIGHT | ONE PIECE | ||
|---|---|---|---|---|---|---|---|---|---|
| (in) | (in) | (mm) | (psi) | (psi) | (in) | (mm) | (lbs/ft) | COUPLINGS | |
| PX350-12 | 3⁄4 | 1.1 | 28.00 | 3500 | 14000 | 5 | 127.00 | 0.61 | coupling_PX350 |
