The Flextral NT300-20 (NT300-20) is a robust hydraulic hose designed for high-pressure applications, featuring a 1.25-inch internal diameter and a maximum working pressure of 5000 psi. This model is part of the NT300 series and is constructed with a nitrile tube and four spirals of high-tensile steel wire reinforcement, making it exceptionally strong yet flexible with a minimum bend radius of 15 inches. The hose's outer diameter measures 1.74 inches or 44.30 mm, supporting lengths from 12 to 1200 inches. The NT300-20 exceeds the performance requirements of SAE 100R12 and EN856 standards, as well as R9R4SH specifications. It is equipped with an abrasion-resistant synthetic rubber cover that meets MSHA fire resistance standards, ensuring durability and safety in harsh environments. This model uses NVS series couplings and supports both non-skive (N) and skive (VS) coupling types. With its broad temperature range from -54°C to 121°C (-65°F to 250°F), the NT300-20 is suitable for various hydraulic systems using petroleum, polyol ester, or water-glycol based fluids. Its flexibility and resistance to wear make it ideal for environments requiring frequent bending and movement of hoses. Additionally, it meets SAE J1942/1 USCG – H accepted standards, highlighting its suitability for maritime applications where high-performance and compliance with safety regulations are critical.
The Flextral NT300-20 (NT300-20) is a robust hydraulic hose designed for high-pressure applications, featuring a 1.25-inch internal diameter and a maximum working pressure of 5000 psi. This model is part of the NT300 series and is constructed with a nitrile tube and four spirals of high-tensile steel wire reinforcement, making it exceptionally strong yet flexible with a minimum bend radius of 15 inches. The hose's outer diameter measures 1.74 inches or 44.30 mm, supporting lengths from 12 to 1200 inches. The NT300-20 exceeds the performance requirements of SAE 100R12 and EN856 standards, as well as R9R4SH specifications. It is equipped with an abrasion-resistant synthetic rubber cover that meets MSHA fire resistance standards, ensuring durability and safety in harsh environments. This model uses NVS series couplings and supports both non-skive (N) and skive (VS) coupling types. With its broad temperature range from -54°C to 121°C (-65°F to 250°F), the NT300-20 is suitable for various hydraulic systems using petroleum, polyol ester, or water-glycol based fluids. Its flexibility and resistance to wear make it ideal for environments requiring frequent bending and movement of hoses. Additionally, it meets SAE J1942/1 USCG – H accepted standards, highlighting its suitability for maritime applications where high-performance and compliance with safety regulations are critical.
NT300 Exceeds 100R12
Meets or exceeds the requirements of SAE 100R12 / EN856, R9R/4SH.
Tube: Nitrile
Reinforcement: Four spirals of high-tensile steel wire
Cover: Synthetic rubber, high-abrasion resistant, meets requirements of MSHA fire resistance standards
Temperature: -54°C to +121°C (-65°F to +250°F)
Packaging: Coils
Application: NT300 is ideal for hydraulic systems with petroleum, polyol ester, or water/glycol based fluids The hose is very flexible with a bending radius less than standard spiral hose and a high-abrasion resistant cover. SAE J1942/1 USCG – H accepted.
| PART NUMBER | HOSE I.D. | HOSE O.D. | MAX W.P. | MIN. BURST PRESSURE | MIN. BEND RADIUS | WEIGHT | ONE PIECE Non-Skive | ONE PIECE Skive | ||
|---|---|---|---|---|---|---|---|---|---|---|
| (in) | (in) | (mm) | (psi) | (psi) | (in) | (mm) | (lbs/ft) | COUPLINGS | COUPLINGS | |
| NT300-20 | 11⁄4 | 1.74 | 44.30 | 5000 | 20000 | 15 | 380.00 | 1.55 | N | VS |
