FLEXTRAL
GX-24

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Flextral directly.***
The Flextral GX-24 (GX-24) is a robust hydraulic hose designed for a variety of applications requiring a durable and flexible solution. This hose is part of the GX series and features an internal diameter of 1.5 inches, with an outer diameter of 1.97 inches or 50.10 mm, ensuring it can handle a maximum working pressure of 725 psi and a minimum burst pressure of 2900 psi. The GX-24 is constructed with a nitrile tube and reinforced by one braid of high-tensile steel wire, making it highly resistant to abrasion, oil, and weather conditions. The synthetic rubber cover is also MSHA approved, which underscores its quality and safety standards. The hose's capabilities are further enhanced by its temperature range tolerance from -40°C to +100°C (-40°F to +212°F), with intermittent use up to 120°C (248°F). This makes it suitable for transporting petroleum-based hydraulic fluids, gasoline, water, diesel fuels, lubricating oils, biodegradable hydraulic oil, and fire-resistant synthetic polyesters. The GX-24 can be used in various lengths ranging from a minimum of 12 inches to a maximum of 1200 inches and has been engineered to maintain flexibility with a minimum bend radius of 20 inches or 500 mm. Flextral ensures that this hose meets or exceeds the requirements set forth by SAE 100R1AT EN853 DIN 20022 1SN ISO 1436 Type 1 standards. It is available in packaging options including reels for sizes from 3/16 inch to 1 inch and coils for sizes from 1¼ inch to 2 inches. The coupling series recommended for this model is the EN series, which complements its design and specifications for optimal performance in demanding hydraulic applications.
